SF Mini Windlass


SF MINI 500W 12V

SKU: STRESS FREE MINI - Categories: , Tag:


The SF Mini Windlass is just like having an extra crew member tending the anchor for you raising and lowering your anchor quickly, safely and effortlessly. There is no need to tie off your anchor rope, no racing down to the bow to drop or raise the anchor. No tangled rope and chain in the anchor well. No strained back or frustrated amateur crew. No rushing around the boat to move your mooring.

Simply drive the boat to where you want to fish, push a button and the anchor is lowered quickly without fuss or bother. It is even automatically secured. You can lower and retrieve your anchor rope using our Australian made electric anchor winches at a rate between 80 and 90 feet per minute! The revolutionary Stress-Free Marine electric drum anchor winch is available in a range of capacities, and there’s one designed just to fit into your boat.

Additional information

Weight N/A
Dimensions 17 × 17 × 11 in

Mini, Mini Free Fall






Mini (Small) Standard Stress Free
Suitable for boats from 4 – 6 meters
Fits neatly into the anchor well
The motor can be mounted at 30, 45 and 90 degrees to suit the configuration of the anchor well
500 watt motor
Constructed from 316 marine grade stainless steel
Maximum lifting capacity 195 kilos (when the drum diameter is small)
Holding capacity at anchor is   1800 kilos
Rated to 80 amps
Normal running the Stress Free will use 25 – 30 amps and under load up to 55 amps
To protect the motor, the circuit breaker will trip out if there is a power overload (for example if   the anchor is stuck on the bottom)
Recommend dual batteries with   the battery switch on BOTH Can be deck mounted
Drum capacity
75 meters of 8mm nylon plus 6 meters of chain OR
100 meters of 6mm double braid eye spliced to 5 meters of 8mm nylon and 6 meters of 6mm short link chain
The gearbox mounting holes allow the motor and drive to be installed at 4 angles to suit different   anchor well configurations
 Another 8 adjustment angles are available at 30º and 45º from each of the basic 4 mounting holes.
NB: The amount of chain can be lengthened or shortened to meet individual needs.
In these situations the amount of rope must be tailored to ensure there is a maintained clearance between the chain and the baseplate.
