Genius GP2 1500 Horizontal Wndlass

GP2 1500 Horizontal Windlass

$2,914.89 – $3,234.33

SKU: GP2 1500 Categories: , Tag:

Description

The GP2 1500 is a Horizontal windlass application windlass perfect for boats for limited space in the anchor locker. This unit comes equipped with an enclosed motor and epicyclical gearbox. The casing is composed of plastic composite material for the 500 W unit. This unit also has a manual free fall capability for quick anchoring. The unit is sold complete with the windlass, solenoid unit, clutch handle, mounting hardware, and users manual.

GP2 500 150 W 6 – 7 m 20 – 23 ft
GP2 1200 250 W 6 – 7 m 20 – 23 ft
GP2 1500 500 W 6 – 9 m 20 – 29 ft
GP2 2000 800 W 8 – 12 m 26 – 39 ft
GP2 500 GP2 1200FF GP2 1500-2000 GP2 1500-2000D
Available only in
composite material and without drum.		 Available with (D) or without drum and in Free Fall (FF) version.
Windlasses are equipped with an epicyclical gearbox that provides much higher efficiency (+40% compared to equivalent traditional gearboxes).



GYPSY 6 mm 7 mm – 1/4″ 8 mm 5/16″
CHAIN 6 mm 6 mm 7 mm 7 mm 1/4″ 1/4″ 8 mm 8 mm 5/16″
DIN 766 ISO DIN 766 ISO G4 BBB DIN 766 ISO G4
ROPE 1/2″ (12,7 mm)

The values in the table refer to a three-strand polyester rope with a rope/chain splice manufactured with the Quick® system.

Additional information

Weight N/A
Dimensions 17 × 17 × 11 in
Drum

,

Gypsy Size

, ,

Series

Voltage

12V
Freefall

Yes, No

Specifications

Standard version
 GP2 1500 / D-GP2 1500FF
Motor   power 500W
Motor   supply voltage 12 V
Maximum   pull 1499 lb
Maximum   working load 551 lb
Working   load 187 lb
Current   absorption @ working load (1) 76 A
Maximum   chain speed (2) 83 ft/min
Maximum chain speed @ working load (2) 33 ft/min
Weight –   Mini Genius 22 lb
Weight –   Mini Genius with drum 25.3 lb
Weight –   Mini Genius free fall 24 lb
