Circuit Breaker
$154.00 – $253.00
The Quick “slow burn” hydraulic magnetic circuit breaker offers protection when using direct currents
Description
The Quick “slow burn” hydraulic magnetic circuit breaker offers protection when using direct currents. In over-current situations, they will trip, break the circuit and protect the equipment. They may be reset manually and are suitable for up to 80 Vdc.
Additional information
| Weight | 1 lbs |
|---|---|
| Dimensions | 1 × 1 × 1 in |
| Amps | 40A, 50A, 60A, 80A, 100A |
Specifications
|
Models
|
10040 | 10050 | 10060 | 10080 | 10100 |
| Trip current | 40 A | 50 A | 60 A | 80 A | 100 A |
| Operating voltage | Max 80 Vdc | ||||
| Operating temperature | – 40° C ÷ + 85° C | ||||
| Motor Wattage | 12V | 24V |
| 150 | 40A | – |
| 250 | 40A | – |
| 300 | 50A | – |
| 500 | 60A | 40A |
| 700 | 50A | 40A |
| 1000 | 80A | 50A |
| 1400 | 100A | 50A |
| 1500 | 100A | 50A |
| 1700 | – | 60A |
| 2000 | – | 80A |
| 2300 | – | 80A |
| 3000 | – | 100A |
