Edwin N

Edwin N 2W IP40 - Image 2

Edwin N 2W IP40 - Image 3

Edwin N 2W IP40

Price range: $69.39 through $79.28

Bulb Color

Trim Finish

Clear

SKU: Edwin-N Categories: LED Lighting, Lighting, Recessed Downlights

Description

The Edwin N is an IP40 recessed Power LED downlight. It has an 72mm round trim composed of AISI 316 stainless steel and a frosted lens.

Additional information

Weight	N/A
Dimensions	0.25 × 0.25 × 0.25 in
Bulb Color	Daylight, Warm
Trim Finish	White, Titanium

Specifications

Specifications

Power type	Constant Voltage
Light source	HIGH LUMINOSITY
Supply	10 ÷ 30 V
Power consumption	2 W
Current consumption	0.09 A @ 24V
Average lifetime	50,000 h
IP security degree	40

Dimensions

Frame	Ø 2 53/64″
Recess	51/64″
Hole	Ø 2 1/8″

Design

Frame material	AISI 316 S/STEEL
Finish	MIRROR POLISHED / SATIN / WHITE 9010
Light colors	DAYLIGHT / WARM WHITE
Mounting	SPRINGS

Photometric data

DAYLIGHT	3800-4200 °K
Angle	95°
Light flow	200 lm
Efficiency	58 lm/W
Light Beam – distance 1 m	Ø 1.69 m	114.4 lux
Light Beam- distance 2 m	Ø 3.39 m	28.6 lux
Light Beam- distance 3 m	Ø5.08 m	12.7 lux

WARM WHITE	2800-3100 °K
Angle	95°
Light flow	190 lm
Efficiency	53 lm/W
Light Beam – distance 1 m	Ø 1.69 m	110 lux
Light Beam- distance 2 m	Ø 3.39 m	27.5 lux
Light Beam- distance 3 m	Ø 5.08 m	12.2 lux

Certifications

Dimensions in mm (inches)

DIMMERS

LDIM BUS 2CH

LDIM BUS 2CH

Basic item, for power and functionality alternatives, consult section ACCESSORIES

LED Protection: Spike protected ± 500V Polarity sensitive: YES
