Marina XP HP 4W
$147.00 – $177.87
Description
The Marina XP HP 4W is an IP66 recessed Power LED downlight. It has an 79mm round trim composed of AISI 316 stainless steel and a frosted lens.
Additional information
Weight | N/A |
---|---|
Dimensions | 0.25 × 0.25 × 0.25 in |
Options | MARINA XP HP LED Daylight 4W 1030V S.Steel, MARINA XP HP LED Warm 4W 1030V S.Steel |
Specifications
Specifications
Power type | Constant Voltage |
Light source | LED |
Supply | 10 ÷ 30 V |
Power consumption | 4 W |
Current consumption | 0.17 A @ 24V |
Average lifetime | 50,000 h |
Dimmable | Yes |
IP security degree | 66 |
Dimensions
Frame | SQ; 3 7/64″ |
Recess | 1 7/64″ |
Hole | Ø 2 9/16″ |
Design
Frame material | AISI 316 S/STEEL |
Finish | MIRROR POLISHED / WHITE 9010 |
Light colors | DAYLIGHT / WARM WHITE |
Mounting | SCREWS |
Photometric data
WARM WHITE | 2800-3100 °K | |
Angle | 55° | |
Light flow | 225lm | |
Efficiency | 49 lm/W | |
Light Beam – distance 1 m | Ø1.04 m | 208.5 lux |
Light Beam- distance 2 m | Ø 2.09 m | 52.1 lux |
Light Beam- distance 3 m | Ø 3.13 m | 23.2 lux |
DAYLIGHT | 3800-4100 °K | |
Angle | 55° | |
Light flow | 295lm | |
Efficiency | 49 lm/W | |
Light Beam – distance 1 m | Ø1.04 m | 283.4 lux |
Light Beam- distance 2 m | Ø 2.09 m | 70.9 lux |
Light Beam- distance 3 m | Ø 3.13 m | 31.5 lux |
Certifications
DIMMERS
LDIM BUS 2CH
LDIM BUS 2CH
Basic item, for power and functionality alternatives, consult section ACCESSORIES
LED Protection: Spike protected ± 500V Polarity sensitive: YES
