Bryan C 2W IP40

$66.00$88.00

Clear

Description

The Bryan Club is an IP40 recessed Power LED downlight. It has an 72mm round trim composed of AISI 316 stainless steel and a frosted lens.

Additional information

Weight N/A
Dimensions 0.25 × 0.25 × 0.25 in
Bulb Color

Daylight, Warm, Red, Warm/Red, Daylight/Red, Warm/Blue

Trim Finish

White, Satin, Stainless Steel

Specifications

Specifications

Power type Constant Voltage
Light source HIGH LUMINOSITY
Supply 10 ÷ 30 V
Power consumption 2 W
Current consumption 0.09 A @ 24V
Average lifetime 50,000 h
Dimmable Yes
IP security degree 40

Dimensions

Frame Ø 2 53/64″
Recess 51/64″
Hole Ø 2 1/8″

Design

Frame material AISI 316 S/STEEL
Finish MIRROR POLISHED / SATIN / WHITE 9010
Light colors DAYLIGHT / WARM WHITE
Mounting SPRINGS

Photometric data


 DAYLIGHT 3800-4200 °K
Angle 100°
Light flow 115 lm
Efficiency 58 lm/W
Light Beam – distance 1 m Ø 2.43 m 44.4 lux
Light Beam- distance 2 m Ø.4.85m 11.1 lux
Light Beam- distance 3 m Ø 7.28 m 4.5 lux

 WARM WHITE 2800-3100 °K
Angle 100°
Light flow 105 lm
Efficiency 53 lm/W
Light Beam – distance 1 m Ø 2.43 m 40.8 lux
Light Beam- distance 2 m Ø 4.85 m 10.2 lux
Light Beam- distance 3 m Ø 7.28 m 4.5 lux

Certifications

Dimensions in mm (inches)

DIMMERS

LDIM BUS 2CH

LDIM BUS 2CH

LDIM BUS 2CH

Basic item, for power and functionality alternatives, consult section ACCESSORIES
LED Protection: Spike protected ± 500V Polarity sensitive: YES
